产品介绍
| 法兰直径 | 100 mm, |
| 电源电压 | 5V : 5V in/out, 30V : 5-30V in/out, 10 - 30Vdc, |
| 连接类型 | 1 mt Cable, 2 mt Cable, 5 mt Cable, 7 mt Cable, 10 mt Cable, M12/4pin, M12/5pin, M16/7pin, M16/14pin, M23/12pin, |
| 轴直径 | 26 mm, 28 mm, 30 mm, 32 mm, 38 mm, 40 mm, 42 mm, 44 mm, |
| 脉冲 | 1024, 2000, 2048, 2500, 4000, 4096, 5000, 8000, 8192, 10000, |
| 输出电路 / 推拉 | A:1, AB:2, ABZ:3, AB+A'B:4, ABZ + A'B'Z':6, |
| 产品组 | Incremental Rotary Encoders, |
